Connect cameras and sensors

Updated: April 19, 2023

You can connect various cameras and sensors to your R-Car V3H to use live video feeds and live sensor data. You can also connect GigE Vision-compliant cameras to run with the image.

After you connect your sensors to the R-Car V3H, you must make configuration changes. Depending on the hardware that you connect, custom SLM and sensor configuration files may be needed. For more information, see the Configure cameras and sensors on the reference image topic.

Connect the AMI MINICube RDACM24 cameras to the V3H

You can connect up to four RDACM24 cameras to your board:


Figure 1. R-Car V3H connected to four cameras

Configure GigE cameras

You can connect GigE cameras (also known as network cameras and IP cameras) that are compliant to the GigE Vision standard. The camera doesn't need to be connected to your target, but it must be connected to the same network as your target.
