Information about the configuration of the on-chip and off-chip cache system.
As well as information about the configuration of the on-chip and off-chip cache system, the cacheattr area contains the control() kernel callout used for cache control operations.
The system page cacheattr_entry structure is filled by the following startup library functions:
- init_cpuinfo() looks after caches implemented on the CPU itself.
- init_cacheattr() looks after board-level caches.
Each entry in the cacheattr area consists of the following:
- next
- Index to next lower level entry
- line_size
- Size of cache line, in bytes
- num_lines
- Number of cache lines
- flags
- See “flags” below.
- control
- Kernel callout supplied by startup code (see “Cache control” in the Kernel Callouts chapter).
The total number of bytes described by a particular cacheattr entry is defined by line_size × num_lines.
flags
The flags parameter is a bitmapped variable consisting of the following:
| This constant: | Means that the cache: |
|---|---|
| CACHE_FLAG_INSTR | Holds instructions. |
| CACHE_FLAG_DATA | Holds data. |
| CACHE_FLAG_UNIFIED | Holds both instructions and data. |
| CACHE_FLAG_SHARED | Is shared between multiple processors in an SMP system. |
| CACHE_FLAG_SNOOPED | Implements a bus-snooping protocol. |
| CACHE_FLAG_VIRT_TAG | Cache is virtually tagged. |
| CACHE_FLAG_VIRTUAL | Is virtually tagged. |
| CACHE_FLAG_WRITEBACK | Does write-back, not write-through. |
| CACHE_FLAG_CTRL_PHYS | Takes physical addresses via its control() function. |
| CACHE_FLAG_SUBSET | Obeys the subset property. This means that one cache level caches something from another level as well. As you go up each cache level, if something is in a particular level, it will also be in all the lower-level caches as well. This impacts the flushing operations of the cache in that a “subsetted” level can be effectively “ignored” by the control() function, since it knows that the operation will be performed on the lower-level cache. |
| CACHE_FLAG_NONCOHERENT | Is noncoherent on SMP. |
| CACHE_FLAG_NONISA | Doesn't obey ISA cache instructions. |
| CACHE_FLAG_NOBROADCAST | Cache ops aren't broadcast on bus for SMP. |
| CACHE_FLAG_VIRT_IDX | Cache is virtually indexed. |
| CACHE_FLAG_CTRL_PHYS64 | Control function takes 64-bit paddr (see “Cache control” and “Patcher routines”). |
Organization of cacheattr entries
The cacheattr entries are organized in a linked list, with the next member indicating the index of the next lower cache entry. Some architectures have separate instruction and data caches at one level, but a unified cache at another level. This linking of entries allows the system page to efficiently contain the information for the different cache levels.
The cpuinfo area's ins_cache and data_cache members provide index pointers to cacheattr tables, respectively to the instruciton cache and to the data cache.
Since the cpuinfo structure is an array which for SMP systems is indexed by the CPU number, it is possible to construct a description of caches for CPUs with different cache architectures. Below is a diagram showing a two-processor system, with separate L1 instruction and data caches as well as a unified L2 cache:
Figure 1. Two-processor system with separate L1 instruction and data caches, and a unified L2 cache.Given the memory layout presented in the diagram above, here's what the cpuinfo and cacheattr fields will look like:
/* * CPUINFO */ cpuinfo [0].ins_cache = 0; cpuinfo [0].data_cache = 1; cpuinfo [1].ins_cache = 0; cpuinfo [1].data_cache = 1; /* * CACHEATTR */ cacheattr [0].next = 2; cacheattr [0].linesize = linesize; cacheattr [0].numlines = numlines; cacheattr [0].flags = CACHE_FLAG_INSTR; cacheattr [1].next = 2; cacheattr [1].linesize = linesize; cacheattr [1].numlines = numlines; cacheattr [1].flags = CACHE_FLAG_DATA; cacheattr [2].next = CACHE_LIST_END; cacheattr [2].linesize = linesize; cacheattr [2].numlines = numlines; cacheattr [2].flags = CACHE_FLAG_UNIFIED;
