`PtPane`

A container for organizing widgets

Class hierarchy:

PtWidget → PtBasic → PtContainer → PtPane

For more information, see the diagram of the widget hierarchy.

PhAB icon:

PtPane button in PhAB

Public header:

<photon/PtPane.h>

Description:

PtPane is a container widget that's useful for logically or visually grouping widgets in an application. Any child widgets that extend beyond the canvas of the PtPane widget are clipped.

PtPane

A dialog box featuring several PtPane widgets.

Inherited resources:

If the widget modifies an inherited resource, the “Default override” column indicates the new value. This modification affects any subclasses of the widget.

Resource	Inherited from	Default override
Pt_ARG_ANCHOR_FLAGS	`PtWidget`	Pt_LEFT_ANCHORED_LEFT\| Pt_RIGHT_ANCHORED_LEFT\| Pt_TOP_ANCHORED_TOP\| Pt_BOTTOM_ANCHORED_TOP
Pt_ARG_ANCHOR_OFFSETS	`PtWidget`
Pt_ARG_AREA	`PtWidget`
Pt_ARG_BANDWIDTH_THRESHOLD	`PtBasic`	Not used by this class.
Pt_ARG_BASIC_FLAGS	`PtBasic`	Pt_ALL_OUTLINES \| Pt_ALL_BEVELS \| Pt_FLAT_FILL
Pt_ARG_BEVEL_WIDTH	`PtWidget`	1
Pt_ARG_BITMAP_CURSOR	`PtWidget`
Pt_ARG_BEVEL_COLOR	`PtBasic`
Pt_ARG_BEVEL_CONTRAST	`PtBasic`
Pt_ARG_COLOR	`PtBasic`
Pt_ARG_CONTAINER_FLAGS	`PtContainer`
Pt_ARG_CONTRAST	`PtBasic`
Pt_ARG_CURSOR_COLOR	`PtWidget`
Pt_ARG_CURSOR_TYPE	`PtWidget`
Pt_ARG_DARK_BEVEL_COLOR	`PtBasic`
Pt_ARG_DARK_FILL_COLOR	`PtBasic`
Pt_ARG_DATA	`PtWidget`
Pt_ARG_DIM	`PtWidget`
Pt_ARG_EFLAGS	`PtWidget`
Pt_ARG_EXTENT	`PtWidget`
Pt_ARG_FILL_COLOR	`PtBasic`
Pt_ARG_FILL_LAYOUT_INFO	`PtContainer`
Pt_ARG_FILL_PATTERN	`PtBasic`
Pt_ARG_FLAGS	`PtWidget`	Pt_HIGHLIGHTED
Pt_ARG_GRID_LAYOUT_DATA	`PtWidget`
Pt_ARG_GRID_LAYOUT_INFO	`PtContainer`
Pt_ARG_HEIGHT	`PtWidget`
Pt_ARG_HELP_TOPIC	`PtWidget`
Pt_ARG_HIGHLIGHT_ROUNDNESS	`PtBasic`
Pt_ARG_INLINE_COLOR	`PtBasic`
Pt_ARG_LAYOUT_DATA	`PtWidget`
Pt_ARG_LAYOUT_INFO	`PtContainer`
Pt_ARG_LIGHT_BEVEL_COLOR	`PtBasic`
Pt_ARG_LIGHT_FILL_COLOR	`PtBasic`
Pt_ARG_MARGIN_HEIGHT	`PtBasic`
Pt_ARG_MARGIN_WIDTH	`PtBasic`
Pt_ARG_MAXIMUM_DIM	`PtWidget`
Pt_ARG_MINIMUM_DIM	`PtWidget`
Pt_ARG_OUTLINE_COLOR	`PtBasic`
Pt_ARG_POINTER	`PtWidget`
Pt_ARG_POS	`PtWidget`
Pt_ARG_RESIZE_FLAGS	`PtWidget`	0
Pt_ARG_ROW_LAYOUT_DATA	`PtWidget`
Pt_ARG_ROW_LAYOUT_INFO	`PtContainer`
Pt_ARG_STYLE	`PtBasic`
Pt_ARG_TITLE	`PtContainer`
Pt_ARG_TITLE_FONT	`PtContainer`
Pt_ARG_TRANS_PATTERN	`PtBasic`
Pt_ARG_USER_DATA	`PtWidget`
Pt_ARG_WIDTH	`PtWidget`
Pt_CB_ACTIVATE	`PtBasic`
Pt_CB_ARM	`PtBasic`
Pt_CB_BALLOONS	`PtContainer`
Pt_CB_BLOCKED	`PtWidget`
Pt_CB_CHILD_ADDED_REMOVED	`PtContainer`
Pt_CB_CHILD_GETTING_FOCUS	`PtContainer`
Pt_CB_CHILD_LOSING_FOCUS	`PtContainer`
Pt_CB_DESTROYED	`PtWidget`
Pt_CB_DISARM	`PtBasic`
Pt_CB_DND	`PtWidget`
Pt_CB_FILTER	`PtWidget`
Pt_CB_GOT_FOCUS	`PtBasic`
Pt_CB_HOTKEY	`PtWidget`
Pt_CB_IS_DESTROYED	`PtWidget`
Pt_CB_LOST_FOCUS	`PtBasic`
Pt_CB_MENU	`PtBasic`
Pt_CB_OUTBOUND	`PtWidget`
Pt_CB_RAW	`PtWidget`
Pt_CB_REALIZED	`PtWidget`
Pt_CB_REPEAT	`PtBasic`
Pt_CB_RESIZE	`PtContainer`
Pt_CB_UNREALIZED	`PtWidget`
