Capture states

Let's consider the state transitions for PCM devices during capture.

The state diagram for a PCM device during capture is shown below.

Figure 1. State diagram for PCM devices during capture.

In the figure above, the oval groups the Overrun, Error, and Unsecure states together to indicate that each state can transition to the Prepared state

The circle surrounding Overrun, Error, and Unsecure states indicates that each state can individually transition to the Prepared state. The transition between SND_PCM_STATUS_* states is the result of executing an API call, or the result of conditions that occur in the hardware:

From To Cause
NOTREADY READY Calling snd_pcm_channel_params() or snd_pcm_plugin_params()
READY PREPARED Calling snd_pcm_capture_prepare(), snd_pcm_channel_prepare(), or snd_pcm_plugin_prepare()
PREPARED RUNNING Calling snd_pcm_read() or snd_pcm_plugin_read(), or calling select() against the capture file descriptors
RUNNING PAUSED Calling snd_pcm_capture_pause() or snd_pcm_channel_pause()
PAUSED RUNNING Calling snd_pcm_capture_resume() or snd_pcm_channel_resume()
RUNNING OVERRUN The hardware buffer became full during capture; snd_pcm_read() and snd_pcm_plugin_read() fail
RUNNING UNSECURE The application marked the stream as protected, the hardware level supports a secure transport (e.g., HDCP for HDMI), and authentication was lost
RUNNING CHANGE The stream changed
RUNNING ERROR A hardware error occurred
OVERRUN, UNSECURE, CHANGE, or ERROR PREPARED Calling snd_pcm_capture_prepare(), snd_pcm_channel_prepare(), or snd_pcm_plugin_prepare()
RUNNING PREEMPTED Audio is blocked because another libasound session has initiated playback, and the audio driver has determined that that session has higher priority

For more details on these transitions, see the description of each function in the Audio Library chapter.
