The phonebook database contains all the PBAP-specific data.
ER diagram
The following entity-relationship (ER) diagram shows the relationships among the tables in the phonebook database:
Figure 1. ER diagram for phonebook database
Sample schema file
The database schema is specified in /db/phonebook.sql, which looks like this:
/* Turn foreign key constraints on */
PRAGMA foreign_keys = ON;
/* Contacts */
CREATE TABLE contacts (
contact_id INTEGER PRIMARY KEY AUTOINCREMENT,
version TEXT NOT NULL,
fn TEXT NOT NULL,
family_name TEXT NOT NULL,
given_name TEXT NOT NULL,
additional_names TEXT,
honorific_prefixes TEXT,
honorific_suffixes TEXT,
sort_string TEXT,
bday TEXT,
geo_lat REAL,
geo_long REAL,
mailer TEXT,
tz TEXT,
title TEXT,
role TEXT,
org TEXT,
note TEXT,
rev TEXT,
url TEXT,
uid TEXT,
prod_id TEXT,
class TEXT
);
/* Emails */
CREATE TABLE emails (
email_id INTEGER PRIMARY KEY AUTOINCREMENT,
contact_id INTEGER NOT NULL REFERENCES contacts ON DELETE CASCADE,
email TEXT NOT NULL
);
CREATE TABLE email_types (
email_type_id INTEGER PRIMARY KEY AUTOINCREMENT,
type TEXT NOT NULL UNIQUE
);
CREATE TABLE emails_types_rel (
email_id INTEGER NOT NULL REFERENCES emails ON DELETE CASCADE,
email_type_id INTEGER NOT NULL REFERENCES email_types
);
/* Telephone numbers */
CREATE TABLE telephone_numbers (
telephone_number_id INTEGER PRIMARY KEY AUTOINCREMENT,
contact_id INTEGER NOT NULL REFERENCES contacts ON DELETE CASCADE,
number TEXT NOT NULL
);
CREATE TABLE telephone_number_types (
telephone_number_type_id INTEGER PRIMARY KEY AUTOINCREMENT,
type TEXT NOT NULL UNIQUE
);
CREATE TABLE telephone_numbers_types_rel (
telephone_number_id INTEGER NOT NULL REFERENCES telephone_numbers ON DELETE CASCADE,
telephone_number_type_id INTEGER NOT NULL REFERENCES telephone_number_types
);
/* Addresses */
CREATE TABLE addresses (
address_id INTEGER PRIMARY KEY AUTOINCREMENT,
contact_id INTEGER NOT NULL REFERENCES contacts ON DELETE CASCADE,
post_office_box TEXT,
extended_address TEXT,
street_address TEXT,
locality TEXT,
region TEXT,
postal_code TEXT,
country_name TEXT
);
CREATE TABLE address_types (
address_type_id INTEGER PRIMARY KEY AUTOINCREMENT,
type TEXT NOT NULL UNIQUE
);
CREATE TABLE addresses_types_rel (
address_id INTEGER NOT NULL REFERENCES addresses ON DELETE CASCADE,
address_type_id INTEGER NOT NULL REFERENCES address_types
);
/* Nicknames */
CREATE TABLE nicknames (
nickname_id INTEGER PRIMARY KEY AUTOINCREMENT,
contact_id INTEGER NOT NULL REFERENCES contacts ON DELETE CASCADE,
nickname TEXT NOT NULL
);
/* Categories */
CREATE TABLE categories (
category_id INTEGER PRIMARY KEY AUTOINCREMENT,
contact_id INTEGER NOT NULL REFERENCES contacts ON DELETE CASCADE,
category TEXT NOT NULL
);
/* Photos */
CREATE TABLE photos (
photo_id INTEGER PRIMARY KEY AUTOINCREMENT,
contact_id INTEGER NOT NULL REFERENCES contacts ON DELETE CASCADE,
photo_data BLOB,
photo_uri TEXT,
encoding_type TEXT,
image_media_type TEXT
);
/* Call Log */
CREATE TABLE calls (
call_id INTEGER PRIMARY KEY AUTOINCREMENT,
contact_id INTEGER REFERENCES contacts ON DELETE SET NULL,
call_type_id INTEGER NOT NULL REFERENCES call_types,
fn TEXT,
number TEXT,
time TEXT NOT NULL,
duration INTEGER
);
CREATE TABLE call_types (
call_type_id INTEGER PRIMARY KEY AUTOINCREMENT,
type TEXT
);
/********
VIEWS
********/
CREATE VIEW emails_view AS
SELECT
emails.email_id,
emails.contact_id,
emails.email,
MAX(CASE WHEN email_types.type = 'PREF' THEN 1 ELSE 0 END) AS pref,
MAX(CASE WHEN email_types.type = 'INTERNET' THEN 1 ELSE 0 END) AS internet
FROM emails
LEFT JOIN emails_types_rel ON emails.email_id = emails_types_rel.email_id
LEFT JOIN email_types ON emails_types_rel.email_type_id = email_types.email_type_id
GROUP BY emails.email_id
ORDER BY pref DESC, emails.email_id DESC;
CREATE VIEW telephone_numbers_view AS
SELECT
telephone_numbers.telephone_number_id,
telephone_numbers.contact_id,
telephone_numbers.number,
MAX(CASE WHEN telephone_number_types.type = 'PREF' THEN 1 ELSE 0 END) AS pref,
MAX(CASE WHEN telephone_number_types.type = 'HOME' THEN 1 ELSE 0 END) AS home,
MAX(CASE WHEN telephone_number_types.type = 'WORK' THEN 1 ELSE 0 END) AS work,
MAX(CASE WHEN telephone_number_types.type = 'VOICE' THEN 1 ELSE 0 END) AS voice,
MAX(CASE WHEN telephone_number_types.type = 'FAX' THEN 1 ELSE 0 END) AS fax,
MAX(CASE WHEN telephone_number_types.type = 'MSG' THEN 1 ELSE 0 END) AS msg,
MAX(CASE WHEN telephone_number_types.type = 'CELL' THEN 1 ELSE 0 END) AS cell,
MAX(CASE WHEN telephone_number_types.type = 'PAGER' THEN 1 ELSE 0 END) AS pager,
MAX(CASE WHEN telephone_number_types.type = 'BBS' THEN 1 ELSE 0 END) AS bbs,
MAX(CASE WHEN telephone_number_types.type = 'MODEM' THEN 1 ELSE 0 END) AS modem,
MAX(CASE WHEN telephone_number_types.type = 'CAR' THEN 1 ELSE 0 END) AS car,
MAX(CASE WHEN telephone_number_types.type = 'ISDN' THEN 1 ELSE 0 END) AS isdn,
MAX(CASE WHEN telephone_number_types.type = 'VIDEO' THEN 1 ELSE 0 END) AS video
FROM telephone_numbers
LEFT JOIN telephone_numbers_types_rel ON telephone_numbers.telephone_number_id
= telephone_numbers_types_rel.telephone_number_id
LEFT JOIN telephone_number_types ON telephone_numbers_types_rel.telephone_number_type_id
= telephone_number_types.telephone_number_type_id
GROUP BY telephone_numbers.telephone_number_id
ORDER BY pref DESC, telephone_numbers.telephone_number_id DESC;
CREATE VIEW addresses_view AS
SELECT
addresses.address_id,
addresses.contact_id,
addresses.post_office_box,
addresses.extended_address,
addresses.street_address,
addresses.locality,
addresses.region,
addresses.postal_code,
addresses.country_name,
MAX(CASE WHEN address_types.type = 'PREF' THEN 1 ELSE 0 END) AS pref,
MAX(CASE WHEN address_types.type = 'HOME' THEN 1 ELSE 0 END) AS home,
MAX(CASE WHEN address_types.type = 'WORK' THEN 1 ELSE 0 END) AS work,
MAX(CASE WHEN address_types.type = 'DOM' THEN 1 ELSE 0 END) AS dom,
MAX(CASE WHEN address_types.type = 'INTL' THEN 1 ELSE 0 END) AS intl,
MAX(CASE WHEN address_types.type = 'POSTAL' THEN 1 ELSE 0 END) AS postal,
MAX(CASE WHEN address_types.type = 'PARCEL' THEN 1 ELSE 0 END) AS parcel
FROM addresses
LEFT JOIN addresses_types_rel ON addresses.address_id
= addresses_types_rel.address_id
LEFT JOIN address_types ON addresses_types_rel.address_type_id
= address_types.address_type_id
GROUP BY addresses.address_id
ORDER BY pref DESC, addresses.address_id DESC;
CREATE VIEW contacts_view AS
SELECT
contacts.contact_id,
contacts.honorific_prefixes AS title,
contacts.family_name AS last_name,
contacts.given_name AS first_name,
contacts.bday AS birthday,
NULL AS anniversary,
contacts.org AS company,
contacts.title AS job_title,
home_phone_1.number as home_phone,
home_phone_2.number as home_phone_2,
work_phone_1.number as work_phone,
work_phone_2.number as work_phone_2,
mobile_phone.number as mobile_phone,
pager_phone.number as pager_phone,
fax_phone.number as fax_phone,
other_phone.number as other_phone,
email_1.email AS email_1,
email_2.email AS email_2,
email_3.email AS email_3,
home_address.street_address AS home_address_1,
home_address.extended_address AS home_address_2,
home_address.locality AS home_address_city,
home_address.country_name AS home_address_country,
home_address.region AS home_address_state_province,
home_address.postal_code AS home_address_zip_postal,
work_address.street_address AS work_address_1,
work_address.extended_address AS work_address_2,
work_address.locality AS work_address_city,
work_address.country_name AS work_address_country,
work_address.region AS work_address_state_province,
work_address.postal_code AS work_address_zip_postal,
photos.photo_uri AS picture,
NULL AS pin,
contacts.uid AS uid,
contacts.url AS web_page,
(SELECT GROUP_CONCAT(categories.category) FROM categories
WHERE categories.contact_id = contacts.contact_id) AS categories,
contacts.note AS note,
NULL AS user1,
NULL AS user2,
NULL AS user3,
NULL AS user4
from contacts
LEFT JOIN telephone_numbers_view home_phone_1 ON contacts.contact_id
= home_phone_1.contact_id AND home_phone_1.home = 1
LEFT JOIN telephone_numbers_view home_phone_2 ON contacts.contact_id
= home_phone_2.contact_id AND home_phone_2.home = 1
AND home_phone_2.telephone_number_id <> home_phone_1.telephone_number_id
LEFT JOIN telephone_numbers_view work_phone_1 ON contacts.contact_id
= work_phone_1.contact_id AND work_phone_1.work= 1
LEFT JOIN telephone_numbers_view work_phone_2 ON contacts.contact_id
= work_phone_2.contact_id AND work_phone_2.work = 1
AND work_phone_2.telephone_number_id <> work_phone_1.telephone_number_id
LEFT JOIN telephone_numbers_view mobile_phone ON contacts.contact_id
= mobile_phone.contact_id AND mobile_phone.cell = 1
LEFT JOIN telephone_numbers_view pager_phone ON contacts.contact_id
= pager_phone.contact_id AND pager_phone.pager = 1
LEFT JOIN telephone_numbers_view fax_phone ON contacts.contact_id
= fax_phone.contact_id AND fax_phone.fax = 1
LEFT JOIN telephone_numbers_view other_phone ON contacts.contact_id
= other_phone.contact_id
AND other_phone.telephone_number_id NOT IN(
COALESCE(home_phone_1.telephone_number_id, 0),
COALESCE(home_phone_2.telephone_number_id, 0),
COALESCE(work_phone_1.telephone_number_id, 0),
COALESCE(work_phone_2.telephone_number_id, 0),
COALESCE(mobile_phone.telephone_number_id, 0),
COALESCE(pager_phone.telephone_number_id, 0),
COALESCE(fax_phone.telephone_number_id, 0))
LEFT JOIN emails_view email_1 ON contacts.contact_id = email_1.contact_id
LEFT JOIN emails_view email_2 ON contacts.contact_id = email_2.contact_id
AND email_2.email_id <> email_1.email_id
LEFT JOIN emails_view email_3 ON contacts.contact_id = email_3.contact_id
AND email_3.email_id <> email_1.email_id AND email_3.email_id <> email_2.email_id
LEFT JOIN addresses_view home_address ON contacts.contact_id
= home_address.contact_id AND home_address.home = 1
LEFT JOIN addresses_view work_address ON contacts.contact_id
= work_address.contact_id AND work_address.work = 1
LEFT JOIN photos ON contacts.contact_id = photos.contact_id
WHERE 0=0
AND (CASE WHEN home_phone_2.telephone_number_id IS NOT NULL
THEN home_phone_1.pref >= home_phone_2.pref ELSE 1 END)
AND (CASE WHEN work_phone_2.telephone_number_id IS NOT NULL
THEN work_phone_1.pref >= work_phone_2.pref ELSE 1 END)
AND (CASE WHEN email_2.email_id IS NOT NULL THEN email_1.pref >= email_2.pref ELSE 1 END)
AND (CASE WHEN email_3.email_id IS NOT NULL THEN email_1.pref >= email_3.pref ELSE 1 END)
GROUP BY contacts.contact_id
ORDER BY LOWER(last_name) ASC, LOWER(first_name) ASC;
