After you unzip a BSP archive, the resulting directory structure looks something like this:
Figure 1. BSP directory structure.In our documentation, we refer to the directory where you've installed a BSP (e.g. /home/myID/my_BSPs/integrator) as the bsp_working_dir. This directory includes the following subdirectories:
- src
- prebuilt
- install
- images
The images subdirectory is where the resultant boot images are placed. It contains (as a minimum) the Makefile needed to build the image(s). Other files that could reside in this directory include:
- custom buildfiles (for flash, etc.)
- EFS buildfiles
- IPL build scripts
