phrelaycfg

Configure remote access to Photon

Syntax:

phrelaycfg [options]

Runs on:

Neutrino

Options:

-h height[%]
The height of the window, in pixels, or as a percentage of the screen height if % is specified.
-Si|m|n
The initial state of the main window (iconified, maximized, or normal).
-s server_name
The name of the Photon server:
If server_name is: This server is used:
node_path node_path/dev/photon
fullpath fullpath
relative_path /dev/relative_path
-w width[%]
The width of the window, in pixels, or as a percentage of the screen width if % is specified.
-x position[%][r]
The x coordinate of the upper-left corner of the window, in pixels, or as a percentage of screen width if % is specified. If r is specified, the coordinate is relative to the current console.
-y position[%][r]
The y coordinate of the upper-left corner of the window, in pixels, or as a percentage of screen height if % is specified. If r is specified, the coordinate is relative to the current console.

Description:

The phrelaycfg command configures remote access to your Photon workspace. The main window looks like this:


The phrelaycfg window.


The phrelaycfg window.

When you uncheck the Enable remote access to your graphical environment checkbox and click Apply, phrelaycfg creates a /etc/system/config/noditto. The presence of this file prevents remote users from connecting to your Photon session using phditto.


Note:
  • You can achieve the same result with the command:
    touch /etc/system/config/noditto
  • You must also configure and run phrelay to allow remote access. If the remote access is over a TCP/IP connection, you must configure and run inetd, which will run phrelay.

Files:

/etc/system/config/noditto
The presence of this file prevents anyone from accessing your Photon workspace from a remote machine.

See also:

inetd, phrelay, phditto

Using the Photon microGUI in the Neutrino User's Guide
